Ramsey HDP 4000 / 4000Y — 4,000 lb Hydraulic Planetary Winch
The Ramsey HDP 4000 / 4000Y is a compact hydraulic planetary winch with a spring-applied, hydraulic-released disc brake and foot or mid-mount installation options. Rated at 4,000 lb. line pull, it's available in standard-drum (4000) and short-drum (4000Y) configurations.
Key Features
- 4,000 lb. line pull capacity
- Spring-applied, hydraulic-released disc brake
- Foot or mid-mount installation
- Manual, air, or blocked free-spool clutch options
- Standard drum (4000) or short drum (4000Y)
Applications
- General lifting, pulling, and winching
- Industrial and commercial use
Specifications
| Model | HDP 4000 / HDP 4000Y |
| Line Pull Capacity | 4,000 lbs (1,814 kg) |
| Gear Reduction | 5.1:1 |
| Weight | 80 lbs (standard drum) / 76 lbs (short drum) |
| Gear System | Planetary |
| Drive Type | Hydraulic |
Pricing and availability by quote — request a quote and we'll get back to you, typically within one business day.
